800XL
Computer from Atari. Released in 1982.
Technical specs
| Feature | Spec |
|---|---|
| CPU | MOS 6502C, 1.79 MHz (NTSC), 1.77 MHz (PAL) |
| CO-processors | GTIA (video output, sprites) POKEY (sound, I/O) * ANTIC (video, display lists) |
| Keyboard | 57-keys full stroke keyboard + 6 function keys |
| RAM | 64 kB (expandable up to 128 kB) |
| ROM | 24 kB |
| Built-in language | Atari BASIC |
| Text modes | five text modes, max: 40 x 24, min: 20 x 12 |
| Graphic modes | 16 graphic modes, maximum : 320 x 192 |
| Colors | 256 (16 colors with 16 intensities) |
| Sound | four channels, 3.5 octaves |
| Power supply | External power supply unit |
| Built in media | None |
Connectors
Right side
- Mouse/Joy (2 pcs)
Top
Rear
- Serial I/O
- Parallel Bus Interface
- Monitor
- Power (5VDC, 1.5A)
